Cervelo Caledonia-5 Red AXS

Cervelo Caledonia-5 Red AXS
$12,750.00
Color: Emerald/Cream
Size: Select size
Wheel Size: 700c
Please select options Unavailable

Details

On the fringes of cycling and triathlon, already endurance-oriented sports, there are athletes pushing their bodies and equipment to the limit. Ultra-distance, but ultra-fast. We call these Big, Stupid Rides, and since the introduction of the Caledonia in 2020, athletes around the world have been exploring just how big and just how stupid those rides can be. These athletes reach for the Caledonia-5. It’s built to handle long-distance, high-speed racing—with fit and handling geared toward comfort, but without sacrificing the Cervelo race bike feeling.

For the new Caledonia-5, we focused on improvements that would be meaningful for the people pushing it to its limits. The biggest thing you’ll notice is the addition of the in-frame storage first seen on P-Series. This isn’t designed to fit a burrito—there’s only room for a small multi-tool, tube, and a CO2 canister. Then we looked to comfort: The seat stays are dropped, similar to Aspero, which makes that rear triangle more acute, and more vertically flexible. At the same time, there’s a bit more downtube stiffness to maintain that pro-level responsiveness Caledonia is known for. You can still stuff some big tires (36mm) in there, and every bike comes with fender mounts.

Like all Cervélos, Caledonia-5 is UCI approved, and carries a lifetime warranty. We make race bikes, and we make them to last.

Geometry Chart:
Frame Size 485154565861
Reach | mm 360 369 378 387 396 405
Stack | mm 505 530 555 580 605 630
Head Tube Angle 70.5° 71.5° 72° 72° 72° 72°
Front Center | mm 580.5 582.7 592.5 609.5 627 644.1
Bottom Bracket Drop | mm 76.5 76.5 74 74 71.5 71.5
Head Tube Length | mm 89.5 110.3 136.3 162.6 191.5 217.8
Top Tube Length | mm 502 522 543 565 581 598
Seat Tube Angle 74.5° 74° 73.5° 73° 73° 73°
Standover Height | mm 701 743 775 798 824 847
Trail | mm 57.8 57.8 57.8 57.8 57.8 57.8
Wheel Size 700C 700C 700C 700C 700C 700C
Fork Offset | mm 60 54 51 51 51 51
Wheelbase | mm 983.3 985.6 996.3 1013.4 1031.8 1048.9
Chainstay Length | mm 415 415 415 415 415 415
Sizes:
Frame SizeRider Height
48 4'22"-5'3"
51 5'3"-5'6"
54 5'6"-5'9"
56 5'8"-5'11"
58 5'11"-6'2"
61 6'2"-6'7"

Specs

Fork Cervélo All-Carbon, Tapered Caledonia-5 Fork
Wheels Front: Reserve 42TA, DT Swiss 240, 12x100mm, 24H, centerlock, tubeless compatible
Rear: Reserve 49TA, DT Swiss 240, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible
Axles Front: Cervélo Aero Thru Axle Front, M12x1.5mm, 127mm length
Rear: Cervélo Aero Thru Axle Rear, M12x1.5mm, 170.5mm length
Tires Vittoria Corsa Pro Control TLR G2.0 700x30c
Bottom Bracket SRAM DUB Ceramic, BBright
Crankset SRAM Red AXS E1, 48/35T, DUB, with power meter
Shifters SRAM Red AXS E1
Front Derailleur SRAM Red AXS E1
Rear Derailleur SRAM Red AXS E1
Cassette/Freewheel SRAM Red E1, 10-36T, 12-Speed
Chain SRAM Red E1
Rotors SRAM Paceline X Centerlock
Handlebars Cervélo HB13 Carbon, 31.8mm clamp
Stem Cervélo ST31 Carbon
Headset FSA IS2 1-1/4, 45° x 45° / 1-1/2, 36° x 45°
Seatpost Cervélo SP24 Carbon
Pedals Sold Separately
Saddle Selle Italia NOVUS BOOST EVO SuperFlow Carbon

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Emerald/Cream / 48cm / 700c 616663229827 0L0CFBRX1C48 CAL347296738
Emerald/Cream / 51cm / 700c 616663229834 0L0CFBRX1C51 CAL349437221
Emerald/Cream / 54cm / 700c 616663229841 0L0CFBRX1C54 CAL341142694
Emerald/Cream / 56cm / 700c 616663229858 0L0CFBRX1C56 CAL342645546
Emerald/Cream / 58cm / 700c 616663229865 0L0CFBRX1C58 CAL346509338
Emerald/Cream / 61cm / 700c 616663229872 0L0CFBRX1C61 CAL346814881
